| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Surface Mount |
| I Hold | 0.5A |
| I Trip | 1.0A |
| V Max | 6.0Vdc |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Surface Mount |
| I Hold | 2.0A |
| I Trip | 4.0A |
| V Max | 5.0vdc |
| Maximum DC Blocking Voltage | 100V |
|---|---|
| Maximum Forward Voltage At IF=1A | 0.8V |
| Maximum RMS Voltage | 70V |
| Maximum Repetitive Peak Reverse Voltage | 100V |
| Typical Junction Capacitance Rating At VR=0V | 100pF |
| Package | DO-214AC(SMA) |
|---|---|
| Maximum DC Blocking Voltage | 20V |
| Peak Forward Surge Current | 40A |
| Operating Junction Temperature Range | -65 To +125℃ |
| Storage Temperature Range | -65 To +125℃ |
| Storage Temperature Range | -65 To +125℃ |
|---|---|
| Maximum DC Blocking Voltage | 30V |
| Peak Forward Surge Current | 50A |
| Maximum RMS Voltage | 21V |
| Operating Junction Temperature Range | -65 To +125℃ |
| Operating Junction Temperature Range | -65 To +125℃ |
|---|---|
| Maximum RMS Voltage | 28V |
| Maximum DC Blocking Voltage | 40V |
| Storage Temperature Range | -65 To +125℃ |
| Average Rectified Current At TA=75℃ | 2A |
| Application | 1.0g |
|---|---|
| DC Sparkover Voltage | 1000V±20% |
| Product Name | Gas Discharge Tube |
| Operating Temperature | -40℃ ~ +90℃ |
| Lead Diameter | 1.5mm |
| SMAJ43A Name | TVS Diodes |
|---|---|
| SMAJ43A Package Type | DO-214AC |
| SMAJ43A Vrwm | 43V |
| SMAJ43A Vbr@It (Min.) | 47.80V |
| SMAJ43A Vbr@It (Max.) | 52.80V |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Radial Lead |
| I Hold | 0.5A |
| I Trip | 1.0A |
| V Max | 130Vdc |
| Tss Name | Thyristor Surge Suppressors (TSS) |
|---|---|
| Item | TSS DIODES |
| Component | Thyristor Surge Suppressors |
| Description | Thyristor Surge Suppressors (TSS) |
| Maximum Leakage Current | Less Than 5μA |
