| SMAJ64A Name | TVS Diodes |
|---|---|
| Package Type | DO-214AC/SMA |
| Vrwm | 64.0V |
| Vbr@It (Min.) | 71.10V |
| Vbr@It (Max.) | 78.60V |
| Description | Thyristor Surge Suppressors (TSS) |
|---|---|
| C0@1MHz, 2Vbias | 50pF Typ. |
| Surge Ratings | 3/4KV(10/700μs) |
| VS@100V/μS | 260V Max. |
| Product Name | Thyristor Surge Suppressors (TSS) |
| Material | Rubber-covered Wire |
|---|---|
| Foot Length | Customizable |
| Operating Ambient Temperature(℃) | -40 ~ +125 |
| Standard | RoHS & Halogen Free (HF) Compliant |
| B Constant (25/50℃)(K) | 3470±1% |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Radial Lead |
| I Hold | 0.2A |
| I Trip | 0.4A |
| V Max | 400Vdc |
| Features | MF52 Pearl-Shape Temperature Measurement NTC Thermistor |
|---|---|
| Material | Enamelled Wire |
| B Constant(25/85℃)(K) | -- |
| Standard | RoHS & Halogen Free (HF) Compliant |
| Foot Length | 200mm |
| Maximum Repetitive Peak Reverse Voltage | 40V |
|---|---|
| Average Rectified Current At TA=75℃ | 1A |
| Maximum RMS Voltage | 28V |
| Maximum DC Blocking Voltage | 40V |
| Peak Forward Surge Current | 40A |
| Peak Forward Surge Current | 100A |
|---|---|
| Package | DO-214AC(SMA) |
| Maximum Average Forward Rectified Current | 3A |
| Maximum RMS Voltage | 21V |
| Maximum Repetitive Peak Reverse Voltage | 30V |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Radial Lead |
| I Hold | 8.0A |
| I Trip | 16.0A |
| V Max | 16V |
| Dimensions | 4.5mm X 3.2mm X 2.7mm |
|---|---|
| Certifications | RoHS,UL |
| Minimum Insulation Resistance | 1GΩ |
| Operating Temperature | -40℃ ~ +90℃ |
| Nominal Impulse Discharge Current | 1KA |
| Operating Voltage | 5.0V |
|---|---|
| Product Category | ESD Array |
| RoHS Compliant | Yes |
| Reel Size | 7 Inch |
| Applications | Cellular Handsets & Accessories, Digital Visual Interface (DVI), RF Circuits, Display Port, USB Ports, MDDI Ports, PCI Express |
