| Surge Ratings | 3/4KV(10/700μs) |
|---|---|
| Description | Thyristor Surge Suppressors (TSS) |
| Package Size | DO-214AC/SMA |
| C0@1MHz, 2Vbias | 120pF Typ. |
| Product Name | Thyristor Surge Suppressors (TSS) |
| Maximum Average Forward Rectified Current | 3A |
|---|---|
| Maximum DC Blocking Voltage | 80V |
| Maximum Repetitive Peak Reverse Voltage | 80V |
| Maximum RMS Voltage | 56V |
| Peak Forward Surge Current | 100A |
| Maximum Repetitive Peak Reverse Voltage | 100V |
|---|---|
| Maximum DC Blocking Voltage | 100V |
| Operating Junction Temperature Range | -55 To +175℃ |
| Peak Forward Surge Current | 50A |
| Maximum Forward Voltage | 0.8V |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Radial Lead |
| I Hold | 0.08A |
| I Trip | 0.16A |
| V Max | 220Vdc |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Surface Mount |
| I Hold | 0.25A |
| I Trip | 0.55A |
| V Max | 9.0Vdc |
| Storage Temperature Range | -65 To +125℃ |
|---|---|
| Package | DO-214AC(SMA) |
| Maximum RMS Voltage | 105V |
| Average Rectified Current At TA=75℃ | 2A |
| Maximum DC Blocking Voltage | 150V |
| P Dtyp. | Multifuse |
|---|---|
| R1 Max | Radial |
| Current | 0.05A - 2.5A |
| Component Name | PPTC Resettable Fuse |
| Package | Surface Mount |
| Item | Metal Oxide Varistor |
|---|---|
| Package | Ф25mm |
| VAC | 250V |
| VDC | 320V |
| Varistor Voltage | 390(351~429)V |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Surface Mount |
| I Hold | 1.75A |
| I Trip | 3.5A |
| V Max | 6.0Vdc |
| Typical Junction Capacitance | 300pF |
|---|---|
| Package | DO-214AC(SMA) |
| Maximum Average Forward Rectified Current | 3A |
| Operating Junction Temperature Range | -65 To +150℃ |
| Peak Forward Surge Current | 100A |
