| Maximum RMS Voltage | 105V |
|---|---|
| Package | DO-214AC(SMA) |
| Typical Junction Capacitance | 300pF |
| Maximum Repetitive Peak Reverse Voltage | 150V |
| Maximum Average Forward Rectified Current | 3A |
| Operating Junction Temperature Range | -55 To +175℃ |
|---|---|
| Maximum RMS Voltage | 56V |
| Peak Forward Surge Current | 50A |
| Maximum Forward Voltage | 0.8V |
| Maximum Average Forward Current | 2A |
| Maximum RMS Voltage | 42V |
|---|---|
| Maximum DC Blocking Voltage | 60V |
| Maximum Repetitive Peak Reverse Voltage | 60V |
| Maximum Forward Voltage | 0.74V |
| Maximum Average Forward Current | 3A |
| Key Words | Metal Oxide Varistor |
|---|---|
| Size | Ф5mm |
| VAC | 50V |
| VDC | 65V |
| Varistor Voltage | 82(74~90)V |
| Vrwm-Reverse Breakdown Voltage | 12.0V |
|---|---|
| Marking Code | 712 |
| Lead Soldering Temperature | 260℃(10sec) |
| Rohs Compliant | Yes |
| Package | SOT-23-3L Package |
| Operating Junction Temperature Range | -65 To +175℃ |
|---|---|
| Maximum DC Blocking Voltage | 50V |
| Maximum Average Forward Current | 3A |
| Maximum Forward Voltage | 0.74V |
| Peak Forward Surge Current | 80A |
| Peak Forward Surge Current | 80A |
|---|---|
| Maximum DC Blocking Voltage | 150V |
| Maximum RMS Voltage | 105V |
| Operating Junction Temperature Range | -65 To +175℃ |
| Maximum Repetitive Peak Reverse Voltage | 150V |
| Item | Diodes For Automotive |
|---|---|
| Package Size | DO-218AB |
| Vr | 28V |
| Ir@Vr @25℃ | 5μA |
| Ir@Vr @175℃ | 150μA |
| Other Name | Arrester Tube |
|---|---|
| Length | φ8*6mm |
| DC Spark-over Voltage @100V/μs | 600V±20% |
| Max. Spark-over Impulse Voltage @100V/μs | 1100V |
| Max. Spark-over Impulse Voltage @1KV/μs | 1200V |
| Component Name | PPTC Resettable Fuse |
|---|---|
| Package | Radial Lead |
| I Hold | 0.2A |
| I Trip | 0.4A |
| V Max | 120Vdc |
