| Maximum Repetitive Peak Reverse Voltage | 30V |
|---|---|
| Package | SOD-123FL |
| Maximum RMS Voltage | 21V |
| Maximum DC Blocking Voltage | 30V |
| Peak Forward Surge Current | 50A |
| Maximum DC Blocking Voltage | 100V |
|---|---|
| Maximum Forward Voltage At IF=1A | 0.8V |
| Maximum RMS Voltage | 70V |
| Maximum Repetitive Peak Reverse Voltage | 100V |
| Typical Junction Capacitance Rating At VR=0V | 100pF |
| Peak Forward Surge Current | 50A |
|---|---|
| Maximum Repetitive Peak Reverse Voltage | 40V |
| Maximum RMS Voltage | 28V |
| Average Rectified Current At TA=75℃ | 3A |
| Operating Junction Temperature Range | -50 To +150℃ |
| Maximum Repetitive Peak Reverse Voltage | 40V |
|---|---|
| Maximum DC Blocking Voltage | 40V |
| Maximum RMS Voltage | 28V |
| Average Rectified Current | 2A |
| Operating Junction Temperature And Storage Temperature Range | -55 To +125℃ |
| Average Rectified Current | 2A |
|---|---|
| Maximum RMS Voltage | 140V |
| Operating Junction Temperature And Storage Temperature Range | -55 To +125℃ |
| Maximum DC Blocking Voltage | 200V |
| Maximum Forward Voltage At IF=1A | 0.95V |
| Reverse Leakage Current At VRRM | 30μA |
|---|---|
| Operating Junction Temperature And Storage Temperature Range | -55 To +150℃ |
| Maximum DC Blocking Voltage | 60V |
| Average Rectified Current | 1A |
| Typical Junction Capacitance Rating At VR=0V | 125pF |
| Other Name | Gas Arrester |
|---|---|
| Size | φ8*6mm |
| DC Spark-over Voltage @100V/μs | 800V±20% |
| Max. Spark-over Impulse Voltage @100V/μs | 1200V |
| Max. Spark-over Impulse Voltage @1KV/μs | 1400V |
| Item | TSS DIODES |
|---|---|
| Maximum Leakage Current | Less Than 5μA |
| Description | Thyristor Surge Suppressors (TSS) |
| Package Size | DO-214AA/SMB |
| Component | Thyristor Surge Suppressors |
| Item | TSS DIODES |
|---|---|
| Component | Thyristor Surge Suppressors |
| Description | Thyristor Surge Suppressors (TSS) |
| Tss Name | Thyristor Surge Suppressors (TSS) |
| Maximum Leakage Current | Less Than 5μA |
| Description | Thyristor Surge Suppressors (TSS) |
|---|---|
| Maximum Leakage Current | Less Than 5μA |
| Item | TSS DIODES |
| Package Size | DO-214AA/SMB |
| Component | Thyristor Surge Suppressors |
